SATATYA SAMAS
Video Management System that Meets Your Enterprise’s Surveillance Needs
Centralized Monitoring and Control
- Monitor Multiple Locations Centrally
- Flexible, Distributed, and Open Architecture
- Matches any Organization Structure and Hierarchy
- Better Situational Awareness and Quick Response Time
Ease of Navigation and Global Search
- Multi-layer E-map to Navigate Between Buildings, Floors, and Cameras
- Monitor Cameras and Sensors Placed in Organizational Layout with Notifications
- Search Footage based on Date-time, Interval, and Source
- Fetch Footage from RSS, Camera, NVR, Backup, and Archive
User-defined Roles and Responsibilities
- Create Custom Roles for Admins, Operators, and Viewers
- Control Access Rights to Features and Sensitive Areas Within the Surveillance System
- Customize According to Your Organization’s Structure and Hierarchy
- Better Control and Management Minimizes Security Breaches
Highlight Features
01
Interoperability
Connects seamlessly with Matrix and third-party IP cameras and NVRs, supports API-level integration with Matrix Access Control Systems
02
Integrated Video Management System
Seamless integration with fire alarms, POS systems, and intrusion systems and database level Integration with boom barriers, weighbridge, and toll booths
03
04
05
06
System Monitoring Alerts
Receive instant notifications for events like recording failure, network disconnection, and camera failure, and access detailed system health reports
07
Optimized Storage Space
Retain high-quality recordings without worrying about storage space with adaptive recording, camera-wise recording retention, and two-level data compression
08
09
SATATYA SAMAS
Technical Specifications
| Parameters | Specifications |
|---|---|
| Functionality and Specifications | |
| Deployment Architecture | Centralized/ Distributed Management and Recording Components |
| Centralized Management and Control | Yes |
| Operating System Platform | Microsoft Windows |
| DBMS Support | MS-SQL |
| Video Wall/ Multi-Display | Yes |
| ONVIF Support | Yes – Profile S. Profile G |
| Mobile App without Cost | Yes – SATATYA VISION (Android and i-OS) |
| Multi User Login | Allowed |
| Single User login on Different Client | Allowed |
| Login Via SSL - Secure Socket Layer Login | Yes |
| Retrieval of Password through OTP (SMS/ E-mail) | Yes |
| E-mail and SMS Templates for Events and Action | Yes (Default and Custom) |
| Creating Custom/ User defined Events/ Alerts | Yes |
| Calling Custom Events through TCP and HTTP API | Yes (Trigger) |
| Integrating COSEC and Custom Database | Yes (For User and Vehicle Details) |
| Activity/ Events Logs | Yes with Custom Search Criteria |
| License Management Configuration | Yes |
| Device based License DongleSupport | Yes (Dongle 200,Device Supported: COSEC VEGA or COSEC PANEL LITE V2) |
| Vehicle and User Attributes | Yes (Add/ Edit/ Delete) |
| Failover Recording Server without additional cost | Yes |
| Redundant Recording Server without additional License | Yes |
| ONVIF RTSP Server without additional License | Yes |
| Transcoding Server without additional License | Yes |
| Server and Entity Connection with Dual ISP (Failover ISP Support) | Yes – Support for 3 different networks Local Network Primary ISP Secondary ISP Applicable to Management Server, Recording Server, FailOver Server, IVA Server and Devices. |
| Fail-Over/ Redundant Server Support and Recording | Yes Local Drive Support Device/ Entity wise redundancy Playback Support |
| Playback Sync for Failover Server/ Redundant Recording Server | Yes |
| Recording Server Configuration | Yes Enable/Disable Server Assigning and Configuring the Devices (Recorders and IPC) to Server (Auto Discovery , Manually and Auto Add Matrix Devices) Set up Storage, Recording and Backup Location and Contact Information |
| Configuring Camera and Device | Yes Profile Setting Stream Parameters and Stream Usage Recording and Backup Events Basic Settings (OSD, Image Appearance) |
| Video Streaming and Recording Format | H.265/ H.264/ MPEG-4/ MJPEG |
| HEVC/ H.265 Streaming over Onvif Protocol | Yes (Server Onvif Version 17.06 and Above) |
| Storage | Local Drives Network Added Storage (NAS) FTP Drive |
| Recording Type | Continuous Recording Manual Recording Motion Recording Event Recording |
| Adaptive Recording | Yes |
| Device/ Edge Initiated Communication | Yes (Support for Matrix Video Recorders and Matrix IPCs) |
| Backup and Archive | Primary Backup with Two Level of Archive |
| Storage and Bandwidth Optimization | Yes |
| Layout wise Resolution and Bandwidth Optimization in Live View | Yes |
| Day Highlight and Clip Capture | Yes |
| Time Lapse Solution and AVI Export | Yes |
| Configuration Cloning | Yes |
| System and Device Time Synchronization | Yes (Over ONVIF) |
| Camera Grouping | Yes |
| PTZ Positions and Tour Configuration | Yes |
| On Screen PTZ Controller | Yes |
| Hardware PTZ Controller Support | Yes (USB) |
| Multiple IPC Export over Synchronous and Asynchronous Mode | Yes |
| Video Export Format | Native (Proprietary Format)/ AVI |
| Watermarking on Export | Yes (Image/ Video) |
| Watermarking on Export Detection through Investigator | Yes (Based on the IVA License) |
| E-Map/ Site-Map | Yes (Server/ Devices/ IPC), Add Electronic Map (.jpg / .bmp Format Multilevel Place the Entity with different Appearance Configure Event Notification |
| E-map through Live View Video Tile | Yes |
| System Monitoring and Health Chart | Yes (Server/ Devices/ IPC),Connected/ Not Connected Entity Stream Receiving CPU Usage/ Memory Usage/ Server Availability Storage Usage and Projections Recording Rate Last and Latest Recording Files availability |
| User Logical View Tree - For Online Users | Yes |
| Provision to mark Device Under Maintenance | Yes with Mandatory Reason |
| COSEC Access Control Integration | Yes |
| I/O Integration with Relay based Sensors | Yes |
| System Setting | Yes User Interface Level – Labels Reports and Templates Input |
| Multi Language Support | Yes User Interface Level – Labels Reports and Templates Input |
| System Account User | Accessibility wise User Rights (Add/ Edit/ Remove), Administrator Operator User |
| File Templates | File Import/ Export Schedules Priority wise Alarms and Custom Alarms |
| API Integration for Third Party POS | Yes (Supported as per API Document) |
| Four Simultaneous Stream support | Yes – Live/ Local/ Recording/ Mobile |
| Multicast Stream Support | Yes (Recording Server; Smart Client; IVA Server; Third Party Client) |
| 64 Camera Video Template with different Matrix | Yes |
| Personalize My View for Live and Page Sequence | Yes |
| Dwell Time Configuration for IP camera | Yes – 1 to 60 S Individual IP camera level configuration |
| Client Bandwidth Optimization | Yes Using Bandwidth available – Yes (Transcoding) As per Video tile occupied on Screen – Yes (Layout wise) |
| Event Log/ Activity Log and Export Yes | Yes |
| Two Way Audio | Yes |
| Audio Broadcasting | Yes |
| Third Party Client - Stream share | Yes Live View and Playback Data using RTSP Streaming Server |
| One Click IPC and Monitor Control on Client | Yes |
| Alarm Management Yes – Generation/ Acknowledgement / Comment/ Close | Yes – Generation/ Acknowledgement / Comment/ Close |
| Operator Generated Event/ Manual Event/ Trigger IVA | Yes |
| Bookmark facility with Retention Lock | Yes |
| Edge Recording | Yes (512 GB at IPC End Matrix Project and Professional Series – 2/3/5 MP IPCs) |
| Edge Storage Retrieval and Playback sync | Yes Connection/ Schedule retrieval of Records |
| Video Pop up/ Email/ SMS/ Snapshot as Live Notification | Yes |
| Reports with Multi Language Support | Yes |
| UI Personalization | Yes – Custom Logo on Client Screens and Video Export |
| Report Personalization | Yes – Custom Logo and Font Size |
| Advance Report with Report Scheduler | Yes |
| Report with Video Clip Hyperlink - Thumbnail and Images | Yes |
