COSEC VYOM
GDPR Compliant Cloud-Based Access Control and Time-Attendance Solution
Scalability
- On-demand Scalability in Sync with Organization Size
- 10,00,000 Users and 65,000 Door Controllers
Real-Time and Easy Accessibility
- Access from Anywhere, Anytime
- Easy Access through Any Internet-Enabled Device
- Real-time Alerts and Notifications through SMS, Email, and WhatsApp
Ease of Use
- Quick Deployment and Setup
- No Software Installation
- 24 × 7 Support
Features
Secured Communication
Secure data transmission with SSL encryption, providing a highly reliable solution that is snoop-proof and hack-proof
01
GDPR Compliance
Prioritizes data privacy, and incorporates user data masking for secure access control and time-attendance user management
02
Multi-Level Data Encryption
Protects Data with multiple data encryption and protective measures offering secure and comprehensive access control and time-attendance solutions
03
Higher Uptime with AWS Server
99.95% server uptime providing reliable access control and time-attendance management round the clock
04
Server-free Solution
Eliminate initial hardware investment and software costs with pay-per-usage, no upfront cost, no server management responsibilities, and no extra charges for upgrades
05
06
Door ARGO FACE SERIES
Door Access Controller
Emphasizes speed and ongoing verification
Two-Door Access Controller
- Finger, Card, PIN and BLE as Credential using External Readers
- Massive Storage Capacity – 50,000 Users, 5,00,000 Event Logs
- Multi Connectivity Options – Wi-Fi, Ethernet, BLE, RS-485
- Support Third Party Access Control Readers over Wiegand Interface
COSEC ARGO FACE
Technical Specifications
| Parameters | Specifications |
|---|---|
| CAPACITY | |
| Face | Yes |
| PIN | Yes |
| Card | COSEC ARGO FACEE:- EM Proximity Card COSEC ARGO FACEM:- MIFARE Classic®/Desfire/NFC Tag COSEC ARGO FACEI:- HID i-class, HID Prox,EM Prox & Mifare/Desfire/NFC Tag *MIFARE and MIFARE Classic® are trademarks of NXP B.V. |
| CAPACITY | |
| BLE User Profiles | 50,000- Mobile |
| Face Templates | 200,000 |
| Max. Templates Per User | 30 |
| Event Log | 5,00,000 |
| FACE RECOGNITION | |
| Algorithm | Deep Learning based Face Recognition |
| Fake Face Detection | Yes |
| Face Identification | 1:200,000 in < 1 sec 1:1 in < 0.5 sec |
| Face Enrolment | Face Recognition Terminal Enrolment Station Upload Images Exception Faces |
| GENERAL SPECIFICATIONS | |
| Dimensions (WxHxD) | 74 mm x 186mm x 50mm |
| Weight | 0.65Kgs (1.433 lbs) |
| Display | 3.5″ IPS LCD (Touch Screen) |
| Display Resolution | 480 x 320 Pixel Yes (Gorilla Glass 3) |
| Display Resolution | 480 x 320 Pixel Yes (Gorilla Glass 3) |
| Gorilla Glass | Yes (Gorilla Glass 3) |
| CPU | Quad Core ARM Cortex-A7 @ 1.5 GHz |
| GPU | Built-in 2 TOPS Neural Network Computing Performance |
| RAM | 2 GB DDR4 |
| Flash memory | 16 GB eMMC16 GB eMMC |
| SD Card | No (Built-in 16GB eMMC provided) |
| Tamper Detection | Yes |
| Buzzer | Yes |
| IR LEDs | Yes |
| Ingress Protection | IP65 |
| Vandal Protection | IK06 |
| Certificate | CE, FCC, BIS, UL, RoHS |
| Operating Temperature | 0°C to +50°C (32°F to 122°F) |
| Storage Temperature | -20°C to 60°C |
| Humidity | 5% to 95 % RH Non-Condensing |
| CAMERA | |
| RGB Camera | 2MP Surveillance Grade, IR Blocked |
| Infrared Camera | 2MP Surveillance Grade, IR Band Pass |
| Camera Sensors | SONY IMX 307, EXMOR Technology, STARVIS Series |
| COMMUNICATION | |
| Ethernet | Yes (10/100 Mbps – 1 port) |
| PoE | Yes (IEEE 802.3 af) |
| WiFi | Yes (802.11 b/g/n) |
| 3G/4G/LTE | Yes (Additional USB Modem) |
| BLE | Yes (Version4.2) (8m Range) |
| USB | Yes (USB 2.0) Micro USB-Type B |
| INTERFACE | |
| Exit Switch Interface | Yes |
| External Reader Support | Yes (MATRIX and 3rd Party) |
| External Reader | Interface, RS232, Wiegand, Power, 12VDC @ 0.5A, LED and Buzzer Control, Allowed – GREEN LED, Buzzer |
| Wiegand | Yes (Selectable IN/OUT) IN: 26 Bit format OUT: Configurable |
| Door Lock Relay | Yes (30VDC @ 2A, Dry Contacts NO/NC/COM) |
| Door Lock Power | Internal PoE Power: 12VDC @ 0.250 A, Internal Adapter Power 12VDC @ 0.5 A, External Power 12VDC @ 2A |
| INSTALLATION | |
| Wall Mount | Yes – Plastic Back Cover with Screws |
| Flush Mount | Yes – Metal Bracket with Screws |
| ACCESSORIES | |
| Power Adapter | 12VDC @ 2A (CE, FCC, UL, BIS) |
Two-Door Access Controller
- Multi-Credential Support – Face, PIN, and QR Code*
- Multi-Connectivity Options – PoE, Ethernet, USB, 3G/4G/LTE
- Massive Storage Capacity – 50,000 Users, 2,00,000 Face Templates
- Deep Face Learning Algorithm with Adaptive Understanding
COSEC ARGO FACE200T
Technical Specifications
| Parameters | Specifications |
|---|---|
| CREDENTIAL SUPPORT | |
| Face | Yes |
| PIN | Yes |
| QR Code | Yes*(*Support Available from V20R7) |
| CAPACITY | |
| User Profiles | 50,000 |
| Face Templates | 200,000 |
| Max. Templates Per User | 30 |
| Event Log | 5,00,000 |
| FACE RECOGNITION | |
| Algorithm | Deep Learning based Face Recognition |
| Fake Face Detection | Yes |
| Face Identification | 1:200,000 in < 1 sec, 1:1 in < 0.5 sec |
| Face Enrolment | Face Recognition Terminal, Enrolment Station, Upload Images, Unidentified Face Enrolment, Adaptive Face Enrolment |
| GENERAL SPECIFICATIONS | |
| Dimensions (WxHxD) | 186mm x 74 mm x 50mm (7.3” x 3” x 2 “) |
| Weight | 650gms (1.433 lbs) |
| Display | 3.5″ IPS LCD (Touch Screen) |
| Display Resolution | 480 x 320 Pixel Yes (Gorilla Glass 3) |
| Display Resolution | 480 x 320 Pixel |
| Gorilla Glass | Yes (Gorilla Glass 3) |
| CPU | Quad Core ARM Cortex-A7 @ 1.5 GHz |
| GPU | Built-in 2 TOPS Neural Network Computing Performance |
| RAM | 2 GB DDR4 |
| Flash memory | 16 GB eMMC |
| SD Card | No (Built-in 16GB eMMC provided) |
| Tamper Detection | No |
| Buzzer | Yes |
| IR LEDs | Yes |
| Ingress Protection | IP65 |
| Vandal Protection | IK06 |
| Certificate | CE, FCC, BIS, RoHS |
| Operating Temperature | 0°C to +50°C |
| Storage Temperature | -20°C to 60°C |
| Humidity | 5% to 95 % RH Non-Condensing |
| CAMERA | |
| RGB Camera | 2MP Surveillance Grade, IR Blocked |
| Infrared Camera | 2MP Surveillance Grade, IR Band Pass |
| Camera Sensors | SONY IMX 307, EXMOR Technology, STARVIS Series |
| COMMUNICATION | |
| Ethernet | Yes (10/100 Mbps – 1 port) |
| PoE | Yes (IEEE 802.3 af) |
| WiFi | No |
| 3G/4G/LTE | Yes (Additional USB Modem) |
| BLE | No |
| USB | Yes (USB 2.0), Micro USB-Type B |
| INTERFACE | |
| Exit Switch Interface | No |
| External Reader Support | No |
| Door Lock Relay | No |
| Door Lock Power | No |
| INSTALLATION | |
| Wall Mount | Yes – Plastic Back Cover with Screws |
| Flush Mount | Yes – Metal Bracket with Screws |
| ACCESSORIES | |
| Power Adapter | No • DC 12V INPUT JACK will be available • Adapter needs to be purchased separately |
